TP-LINK JetStream TL-SG2428P 28-Port 24x10/100/1000 4x Gigabit SFP slots Smart Switch with 24-Port PoE+ mrežno stikalo ponuja centralizirano upravljanje v oblaku z integracijo platforme Omada SDN. Switch uporablja napredne funkcije L2+ poleg L2 pa uporablja tudi (L3/ L4 QoS, ACL, statično usmerjanje in še več). Poleg vseh naprednih funkcij je JetStream TL-SG2428P zaščiten z obilno varnostno strategijo z zaščito naložb v območju LAN.
Poe + izhod
24 vrat PoE + s skupno porabo energije 250 W
Programsko definirano omrežje (SDN) z dostopom v oblaku
Programsko definirano omrežje (SDN- Software Defined Networking) integrira omrežne naprave, vključno z dostopnimi točkami, stikali in prehodi, kar zagotavlja 100% centralizirano upravljanje v oblaku. Omada ustvari zelo razširljivo omrežje, ki ga nadzoruje en sam vmesnik. Na voljo so brezžične in žične povezave, idealne za uporabo v gostinstvu, izobraževanju, prodaji, pisarnah in še več.
TL-SG2428P
6935364030650
TP-LINK
rack / namizni
Managed
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
24x 10/100/1000 Mbps RJ45, 4x Gigabit SFP
24
prepustnost: 56 Gbps
število paketov na sekundo: 41,7 Mpps
24x 802.3at/af, do 250W skupno
Quality of Service
Support 802.1p CoS/DSCP priority
Support 8 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
IPv6 QoS
Voice VLAN
L2 and L2+ Features
Static Routing
DHCP Relay
DHCP Server
IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loopback detection
802.3x Flow Control
LLDP, LLDP-MED
VLAN
Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
MAC/Protocol-based VLAN
Access Control List
L2?L4 package filtering
MAC ACL
IP ACL
Combined ACL
IPv6 ACL
Security
AAA
Port Security
DHCP Snooping
IP-MAC-Port Binding
IPv6-MAC-Port Binding
ARP Inspection
802.1x and Radius Authentication
SSH v1/v2
SSL v3/TLSv1.2
Broadcast/Multicast/Unknown-unicast Storm Control
Dos Defend
IPv6
Dual IPv4/IPv6 stack
Multicast Listener Discovery (MLD) Snooping
IPv6 neighbor discovery (ND)
Path maximum transmission unit (MTU) discovery
Internet Control Message Protocol (ICMP) version 6
TCPv6/UDPv6
IPv6 Applications
DHCPv6 Client
Ping6
Tracert6
Telnet (v6)
IPv6 SNMP
IPv6 SSH
IPv6 SSL
Http/Https
IPv6 TFTP
MANAGEMENT
Omada Apps
Centralized Management
Omada Cloud-Based Controller
Omada Hardware Controller (OC300)
Omada Hardware Controller (OC200)
Omada Software Controller
Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Management Features ? Web-based GUI and CLI management
SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Dual Image
EEE
440 × 220 × 44 mm
24 mesecev
TL-SG2428P, napajalni kabel, rackmount kit, gumijaste noge
